Moisture Proof Black Polyester Film , Two Sides Gloss Polyester Film
| Place of Origin | Guangdong, China (Mainland) |
|---|---|
| Brand Name | Watai |
| Certification | ROSH,SVHC,MSDS,TDS |
| Model Number | WT |
| Minimum Order Quantity | negotiation |
| Price | negotiation |
| Packaging Details | Wooden Packaging |
| Delivery Time | 30 work days |
| Supply Ability | 1000 Tons per |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Black PET Film | Type | Stretch Film |
|---|---|---|---|
| Feature | Moisture Proof | Hardness | Soft |
| Processing Type | Multiple Extrusion | Thickness | 4.5mic --- 250mic |
| Width | 20mm-1500mm | Length | 100m-6000m |
| High Light | black polyester film,pet thin film |
||
Product Description
Black PET Films/resist 150 degrees/matte/ frosted and haze/gloss on two sides
Product Description:
The product can resist 150 degrees for half an hour. This series of PET Films can be classified by surface: gloss on two sides, matte, frosted and haze. The degree of matte can reach 5 (0 when testing with water).
It can be used for shading, laminating, printing, diaphragm, insulating spacer and dust caps. We can customize our product based on your request. We sincerely welcome you to become agent of our products. Wholesale and retail are both accepted.
Specifications:
| Thickness | Width | Length | Paper Core |
| 4.5mic-250mic | 20-1500mm | 100-6000m | 76mm (3 inches) |
Characteristics:
1. This product is Environmentally-friendly, non-toxic, odorless and benzene-free. Solvent is not used during the production, therefore harmless to the Environment and people
2. Stable performance with good resistance to high temperature (150 degrees). We can produce product with surface that has tension and release force.
3. High efficiency. The production efficiency and the product quality can be largely improved when producing products like diaphragm and dust caps which has harsh temperature requirement (sometimes up to 190 degrees).
Typical performance
| Item | Unit | Index | Test method | ||||||||
| Thickness | µm | 12 | 25 | 50 | 75 | 100 | 125 | 188 | 250 | GB12802.2-2004 | |
| Deviation of thickness | % | ±2 | ±2 | ±2 | ±3 | ±3 | ±3 | ±4 | ±4 | ||
| Tensile strength | MD | Mpa | ≥180 | ≥180 | ≥175 | ≥170 | ≥160 | ≥160 | ≥150 | ≥150 | GB12802.2-2004 |
| TD | |||||||||||
| Elongation at break | MD | % | ≥100 | ≥100 | ≥100 | ≥100 | ≥100 | ≥100 | ≥100 | ≥100 | GB12802.2-2004 |
| TD | |||||||||||
| (150℃,30min) | MD | % | ≤1.3 | ≤1.3 | ≤1.3 | ≤1.3 | ≤1.3 | ≤1.3 | ≤1.3 | ≤1.3 | GB12802.2-2004 |
| Heat shrinkage | TD | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | ||
| Haze | % | ≤1.0 | ≤1.0 | ≤1.5 | ≤2.0 | ≤2.6 | ≤3.0 | ≤4.0 | ≤4.0 | GB2410-80 | |
| Wetting tension | mN/m | ≥52 | GB/T 13541-1992 | ||||||||
| Electrical strength | V/µm | ≥100 | ≥100 | ≥95 | ≥90 | ≥80 | ≥66 | ≥66 | GB12802.2-2004 | ||
| Volume resistivity | Ω.m | ≥1×1014 | GB12802.2-2004 | ||||||||
| Relative dielectric constant(50Hz) | 2.9~3.4 | GB12802.2-2004 | |||||||||
| Dielectric loss tangent(50Hz) | ≤3×10-3 | GB12802.2-2004 | |||||||||
