| Transparency: | Opaque | Material: | Black Pet Film |
|---|---|---|---|
| Thickness: | 0.125mm-0.50mm | Length: | 100m-6000m |
| Width: | 100mm-1500mm | Surface: | Bright,Matte |
| Hardness: | Soft | Product Name: | Black Color Bopet Film |
| High Light: | pet thin film,pet film roll |
||
Excellent Mechanical Properties / Sign Printing , Black Halogen-Free Flame Retardant Pc Film
Characteristics:
The film is a black, one side medium sand, the other side matte halogen-free flame-retardant PC film, the UL94 fire rating reaches vtm-0 or V-0, the film has good formability, excellent mechanical properties, good dimensional stability at high temperature and high flame-retardant rating, which is more suitable for the insulation application of power supply, disk drive, bus, TV / display, PC board and business equipment, when pasted with foil It can be used for insulation and EMI / fri shielding.
Typical performance:
| Thickness(mm) | N.Weight per roll(KG) | Pound(LB) | Width × Length mm × m | Width × Length Foot × Foot | |||||
| 0.125(0.005") | 89.3 | 197 | 930×625 | 3'×2049' | |||||
| 0.175(0.007") | 89.3 | 197 | 930×446 | 3'×1462' | |||||
| 0.25(0.010") | 89.3 | 197 | 930×312 | 3'×1023' | |||||
| 0.38(0.015") | 89.3 | 197 | 930×205 | 3'×672' | |||||
| 0.43(0.017") | 89.3 | 197 | 930×181 | 3'×610' | |||||
| 0.50(0.020") | 89.3 | 197 | 930×156 | 3'×512' |
Application:
It has more superior mechanical properties, better appearance quality, more stable and consistent color; because of its good transparency, it has a wide range of applications in printing, which can be used for the printing of panels and labels with flame retardant requirements; it has superior formability, which can be used for the IMD application with flame retardant requirements; it can also be widely used for the lamination insulation of power supply, TV / display, business machine, etc Shelter.
