| Color: | Black | Hardness: | Soft |
|---|---|---|---|
| Thickness: | 0.0125mm-0.25mm | Length: | 500mm-1500mm |
| Width: | 100m-6000m | Processing Type: | Multiple Extrusion |
| Material: | PET | ||
| High Light: | pet thin film,pet film roll |
||
Special film for film circuit , high hardness for keyboard circuit
Characteristics:
Black PET film is a kind of film made by heating dimethyl benzoate and diethanol with the aid of related catalyst, transesterification and vacuum polycondensation, biaxial stretching. The product is environmentally friendly, odorless and benzene free. No solvent is used in the production process, so it is harmless to the environment and people.It inherits the original chemical and physical properties of polyester film, especially with good black coverage, uniform color, smooth and flat surface, no fading, good mechanical properties and thermal stability
Specifications:
| Properties | Unit | Test Values | Testing Standard | ||||||||
| Single Layer Thickness | Average Thickness | μm | 25-100 | ||||||||
| Tensile Strength | MD | MPa | 170 | ASTM D 882 | |||||||
| TD | 200 | ||||||||||
| Elongation at Break | MD | % | 110 | ASTM D 882 | |||||||
| TD | 110 | ||||||||||
| F5 value | MD | MPa | 100 | ASTM D 882 | |||||||
| Thermal Shrinkage 150℃×30min | MD | % | 1.3 | GB/T 13541 | |||||||
| TD | 0.5 | ||||||||||
Application:
The products are mainly used in the fields of tape black slip paper, electroacoustic equipment (sound film, vibration film), gluing, tape, punching, insulating spacer, film line screen printing, electronic insulating gasket, etc.
